Our BNC Connectors are miniature, light-weight and durable units suitable for a wide range of applications. Mating is by a 2-stud bayonet lock.

ELECTRICAL SPECIFICATIONS

Nominal Impedance:	50 Ohms
Frequency Range:	0-4 GHz
Voltage Rating:	AC 500V
Withstanding Voltage:	1500 Volts RMS
Insulation Resistance:	5000 Mega ohms Min.
Temperature Range:	67' to 390' F
Vibration:	Mil. Std. 202 Method 204
Shock:	Mil. Std. 202 Method 202
Moisture Resistance:	Mil. Std. 202 Method 105

MATERIALS

Body Housing	Brass
Male Contact	Brass, Gold Plated
Female Contact	Brass, Gold Plated Crimp
Ferrule	Copper
Gasket	Silicone Rubber
Dielectric	Delrin, Teflon or PBT

  ^•
